MS-63DOC-P

USB-C docking extension system – up to 100m with 60W charging from Host

Description

The MSolutions MS-63DOC-P Docking extender is a revolutionary solution that simplifies installation and consolidates all video, audio and data signals through a single USB-C cable – including a 60W charge of the laptop from the Host unit. More than a simple receiver, the MS-63DOC Device plays the role of a docking extender capable of feeding up to two 4K60 displays (via separate HDMI connections), 3 USB devices including PTZ cameras (via USB 3.2 or USB-C connections) and an audio speaker system. The Device unit also has a built-in IP controller for any 3rd party IP devices.

Key Features

  • Solves the challenge of extending USB 3.2 camera data, video and audio over a single category cable up to 100m
  • A USB channel for up to 5Gbps data connectivity of USB devices across the link
  • Flexible USB extension for: PTZ cameras, hard drives, laptops and other USB peripherals
  • Bi-directional RS-232 serial pass through
  • 1x USB-C & 2x USB-A at Device side
  • 2-port Ethernet hub at Device side
  • Extended mode display – two HDMI ports for two individual streams
  • A built-in programmable IP controller for any 3rd party devices with an IP API

Specifications

  • USB connectivity Host: 1x USB-C (female) – data & video
  • USB connectivity Device: 2X USB-A and 1X USB-C USB3.2 gen1 data
  • Micro-USB connectivity (Host & Device): for product update, and Cloud control (future)
  • On device side, 2X HDMI 4K60 outputs with extended view support
  • RS-232 connectivity (Host & Device): 1x 3-pin phoenix connector, block included
  • Installation requires CAT6A cable or above
  • Power supply: 1 x 12V 2A DC, 1 x 24V 4A DC
  • Power consumption: 7W
  • 2x Ethernet ports RJ-45
  • Individual unit dimensions (WxDxH): 60 x 84 x 25mm
  • Individual unit weight: 300g
  • Package dimensions (WxDxH): 163 x 147 x 85mm
  • Package weight: 350kg
  • Master carton quantity: 18
  • Master carton dimensions (WxDxH): 540 x 270 x 260mm
  • Master carton weight: 10kg
  • Operating temperature: 32°F to 104°F (0°C to 40°C)
  • Storage temperature: -4°F to 140°F (-20°C to 60°C)
  • Operating humidity: 0-80% non condensing

Downloads

MS-63DOC-P Datasheet
MS-63DOC-P Schematic
MS-63DOC-P Images
DisplayLink Drivers - Windows
DisplayLink Drivers - Mac

Package Contents

  • MS-63DOC-P Host & Device
  • 1 x 24V 4A power supply with US, UK & EU territory clips
  • 1 x 12V 2A power supply with US, UK & EU territory clips
  • 1 x 3-pin Phoenix connector
  • 1 x USB-C cable
